Doosan MV-3016L CNC Vertical Machining Center
1 in stock
Used Doosan MV-3016L CNC Vertical Machining Center for Sale. This Doosan MV-3016L has minimal cutting hours and is in good condition.
| Location: | Lake Elsinore, CA |
| SKU: | 105403 |
| Make/Model: | Doosan MV-3016L |
| Condition: | MLS |
| Make: | Kitamura Mycenter |
| Model: | 3XD |
| Year: | 2015/2016 |
| Condition: | MLS |
| Cutting Hours: | 5096 Hours Only |
| Equipped With: |
|---|
| Fanuc Oi-MD Series CNC Control |
| 12,000 RPM High Torque Spindle |
| 26.1 kW High Torque Spindle Motor |
| 24 Automatic High Speed Tool Changer |
| 4798 cm/min Fast Rapid Traverse Rate |
| Through Spindle Coolant |
| High Speed Machining |
| PCMCIA Card Slot |
| MPG Control |
| Rigid Tapping |
| Telescopic Way Covers |
| Flood Coolant System |
| Oil Chiller |
| Chip Conveyor |
| Travels: |
|---|
| X-Axis: 30.0″ |
| Y-Axis: 20.1″ |
| Z-Axis: 20.1″ |
| Rapid Traverse rates X & Y Axis: 4798 cm/min |
| Rapid Travers rates Z Axis: 4201 cm/min |
| Distance Between Spindles: 22″ |
| Travel: |
|---|
| X Axis Travel : 8.1″ |
| Y Axis Travel : 4.1″ (+/-2.1″) |
| Z1 Axis Travel : 22″ |
| B Axis Travel : 20″ (Sub Spindle) |
| C Axis: 360° (0.001°) Both Spindle |
| Rapid Traverse X Axis: 3000 cm/min |
| Rapid Traverse Y Axis: 1001 cm/min |
| Rapid Traverse Z Axis: 3599 cm/min |
| Cutting Feed Rates: 1999 cm/min |
| Spindle Nose to Table (Min.- Max.): 3.93″ – 24.01″ |
| Table: |
|---|
| Length: 33.9″ |
| Width: 19.7″ |
| Max Weight on Table: 800.1 kg |
| Spindle: |
|---|
| Taper Size: 40 |
| Speed Range: 12000 RPM |
| Spindle Power: 26.1 kW |
| Automatic Tool Changer: |
|---|
| Capacity: 24 Station Side Mounted |
| Max Tool Dia: 5.90″ |
| Max Tool Length: 9.45″ |
| General: |
|---|
| Air Required: 80 psi, 4 scfm |
| Power: 220v / 25 kva / 3-Phase |
| Overall Dimensions: 95″ x 88″ x ?” High |
| Weight: lbs |
