*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | MAZAK |
| Model: | SLANT TURN 60 UNIVERSAL 2000 |
| Condition: | Used – Good |
| Equipped With: |
|---|
| Fanuc 18i-T CNC Control |
| 10-Station Turret |
| Box Ways Design |
| 250 mm Big Bore Spindle |
| 610 mm 3-Jaw Chuck |
| Geared Head spindle for powerful torque |
| RS-232 Port |
| Hydraulic Turret |
| Chip Conveyor |
| Coolant System |
| Tailstock |
| Automatic Lubrication system |
| Foot Operated Control for Chuck |
| Capacity: |
|---|
| Max Turning Diameter: 710 mm |
| Max Turning Length: 2000 mm |
| Max Bar Capacity: 250 mm |
| Swing Over Bed: 915 mm |
| Travels: |
|---|
| X Axis Travel: 650 mm |
| Z Axis Travel: 2030 mm |
| Rapid Traverse X Axis: 12,000 mm per Minute |
| Rapid Traverse Z Axis: 8,000 mm per Minute |
| Spindle: |
|---|
| Spindle Nose: A2-15 |
| Spindle Bore: 250 mm |
| Spindle Speed: 0 – 1000 RPM |
| Spindle Motor: 60 HP |
| Turret: |
|---|
| Turret Capacity: 10 Stations |
| Turret Index Time: ? |
| Tailstock: |
|---|
| Tailstock Body Travel: 1800 mm |
| Tailstock Quill Dia.: 125 |
| Tailstock Quill Stroke: 165 |
| Tailstock Taper: MT-5 |
| General: |
|---|
| Power Source: AC 220V, Three Phase, 60 Hz |
| Power Requirement: ? |
| Overall Dimensions: ″ x ″ x ″ High |
| Weight : lbs Approx. |
