Specifications and hours are approximate and for reference only. The machine comes as shown in the images, and accessories are included only if listed on the invoice. Please verify all details before purchase: call +91-97170 69696 or email sales@machinestation.in. All sales are final.
| Equipped With: |
| Mitsubishi 600M CNC Control |
| 64″ X 80″ Table for Die Mold Applications |
| 30 Station Side Mount Tool Changer |
| 50 Taper Geared Head |
| 6000 RPM Spindle |
| Powerful 35 HP high torque spindle motor |
| PCMCIA Card Slot |
| RS-252 Port |
| Spindle Orientation |
| Box Way Construction |
| Portable manual pulse generator |
| Flood coolant with large separate coolant tank Base |
| Flush Chip Disposal with Dual Auger |
| Chip Conveyor |
| Chiller Unit |
| Books and Manuals |
| Travels: |
| X-Axis: 61.75″ |
| Y-Axis: 86.66″ |
| Z-Axis: 36.22″ |
| Distance Between Columns: 102.36″ |
| Spindle Nose to Table (Min.- Max.): 7.4″- 43.7″ |
| Table: |
| Length: 64.96″ |
| Width: 80.31″ |
| T-Slot: 0.87″ Wide X 20 X 7.87″ |
| Max Weight on Table: 22000 lbs |
| Feed rates: |
| Rapid X Y & Z: 590 inch per minute |
| Cutting Feedrate: .04″ – 376″ inch per minute |
| Spindle: |
| Taper Size: 50 |
| Speed Range: 6000 RPM |
| Spindle Power: 35 HP |
| Tool Changer: |
| Capacity: 30 |
| Max Tool Weight: 43 lbs |
| Max Tool Length: 13.77″ |
| Max Tool Dia.: 5.2 – 7.7″ |
| General: |
| Air Required: 100 psi 4 scfm |
| Power: 220v / 3-Phase 65 Kva |
| Floor Dimensions: 224″ X 144″ x 130″ High |
| with Hydraulic Unit Chip Conveyor Chiller unit |
| Weight: 55000 lbs. |
| “No Charges for loading at list Price” |
